  • 3DM-DH3™井下定位传感器和数据记录器
  • 3DM-DH3™井下定位传感器和数据记录器

    产品简介

    3DM-DH3™是井下方向传感器和数据记录仪。它集成了加速度传感器,磁场传感器和温度传感器,以及板载微处理器,嵌入式软件算法,用于配置的非易失性存储器,闪存数据记录存储器和串行通信接口。其外形尺寸,额定温度范围和电源要求针对井下应用进行了优化。3DM-DH3™提供精确的钻孔路径测量,包括倾角,方位角,GTF,MTF,倾角,传感器温度,G-TOT和H-TOT。

    3DM-DH3™是井下方向传感器和数据记录仪。它集成了加速度传感器,磁场传感器和温度传感器,以及板载微处理器,嵌入式软件算法,用于配置的非易失性存储器,闪存数据记录存储器和串行通信接口。其外形尺寸,额定温度范围和电源要求针对井下应用进行了优化。3DM-DH3™提供精确的钻孔路径测量,包括倾角,方位角,GTF,MTF,倾角,传感器温度,G-TOT和H-TOT。


    特点与优势

    全系列最优

    • 精确的井下定位

    • 高速采样率和灵活的数据输出扩展使用,低功耗数据记录



    最容易使用

    • 钻柱中的快速部署输出钻孔路径测量值



    成本效益

    • 为客户的应用降低成本并缩短产品


    上市时间

    • 批量折扣计划



    应用

    • 井下定向垂直


    系统总览

    3DM-DH3™可以开箱即用,可立即用于井下作业,集成到现有系统中以提供电子测量组件,或整合到OEM产品中。



    物理上,3DM-DH3™可以使用其主体的螺纹附件轻松安装到钻柱中。它可以连接到RS-422通信电缆,以便在钻井作业期间对主计算机进行连续的实时测量,或者可以远程部署并作为数据记录器运行,并在通过钻探路径运行后进行数据检索。该装置可以通过通信电缆系绳从平台源或电池供电。



    该装置经过工厂校准,可随时启动。该设备附带易于使用的PC软件,允许用户配置和操作仪器,查看实时测量或下载记录的数据以进行后处理。对于那些开发自己的应用程序的用户,集成商或OEM, 3DM-DH3™附带完整的数据通信协议手册,为开发人员提供完整的仪器命令集。您可以使用任何编码语言和任何计算平台(包括微处理器)轻松开发您自己设计的应用程序



    方向范围

    360˚所有轴(方向角);倾角,方位角,GTF,MTF,倾角,G-TOT,H-TOT

    A / D分辨

    24位加速度计;16位磁力

    角度分辨率

    0.02˚

    准确性



    倾角±0.2˚

    方位角±0.5˚

    角度测量可重复性

    0.1 °

    数字输出速率/记录速

    高达8赫

    输出模式

    加速度和磁场矢量加温度;方向角加温

    数字输出

    RS-422串行(四线全双工)标

    串行数据速率

    115200波

    数据记录容量

    最多32,768条数据记

    电源电压

    +6.0 VDC min,最大+10.0 VDC

    电源电流

    连接到主机时典型值为50 mA典型值,当以8Hz时记录时典型值为16 mA典型值,当以1/4 Hz记录时典型值为50μA典型值,在深度睡眠模式

    连接器

    通孔PCB焊盘(焊接)2 mm间距,2排16针接

    工作温度

    - 40˚C至125˚C(-10˚C至125˚C,推荐使用电池

    外形尺寸

    直径177毫米x 21毫

    重量

    91

    冲击极限

    500 g

    外壳材料

    阳极氧化铝

    软件

    Windows XP, Vista, 7





    The 3DM-DH3™ is a downhole orientation sensor and datalogger. It incorporates acceleration sensors, magnetic field sensors, and temperature sensors, together with an on-board microprocessor, embedded software algorithm, non-volatile memory for configuration, flash datalogging memory, and serial communication interface. Its form-factor, rated temperature range and power supply requirements are optimized for downhole applications. The 3DM-DH3™ provides accurate drill path measurements including Inclination, Azimuth, GTF, MTF, Dip Angle, sensor temperatures, G-TOT and H-TOT.


    Features & Benefits

    Best in Class

    •  precise downhole orientation

    •  high-speed sample rate & flexible data outputs  extended use, low-power data logging


    Easiest to Use

    • rapid deployment in the drill string

    • outputs drill path measurements


    Cost Effective

    • reduced cost and rapid time to market for customer’s applications

    • aggressive volume discount schedule


    Applications

    • Downhole Orientation

    • Vertical Wells


    System Overview

    The 3DM-DH3™ can be deployed out of the box for immediate use in downhole operations, integrated into an existing system to provide an electronic measurement component, or incorporated into an OEM product.

    Physically, the 3DM-DH3™ is easily mounted into the drill string using its body’s threading attachments. It can be tethered to an RS-422 communication cable for continuous real-time measurements to a host computer during drilling operations, or it can be remotely deployed and run as a datalogger, with data retrieval after it has been run through the drill path. The unit can be powered through the communication cable tether from a platform source or by batteries.

    The unit is factory calibrated and ready for use with power-up. The unit ships with easy-to-use PC software which allows the user to configure and operate the instrument, view real-time measurements or download logged data for post-processing.For those users, integrators or OEMs who develop their own applications, the 3DM-DH3™ is shipped with a complete Data Communications Protocol manual which provides the developer with a complete instrument command set. Applications of your own design can readily be developed in any coding language and on any computing platform including microprocessors.
